DPA260 is a 6-channel 19¡±speaker processor for our speaker,Digital Speaker Processor is based D on a powerful analog and digital 4xDSP platforms having the following specifications.
Product number: DPA260 Product type: DSP controller Type: digital, 6-channel AD/DA converter: 24bit Sampling frequency: 48kHz Frequency response: 20 - 20,000Hz Filter type: Linkwitz-Riley, Butterworth, Bessel Filter slew rate: 24dB/oct, 18dB/oct, 12dB/oct, 6dB/oct Dynamic range: 111 (A-weighted)dB Signal-to-noise ratio: > 106dB THD: < 0,005 %
Crosstalk: 107 (+ 20 dBu @ 1 kHz)dB Max. input level: +20 dBu (balanced)dBu Max. output level: +20 dBu (balanced)dBu Input impedance : 27kOhm Output impedance: 120Ohm(s) Controls: Utility, Escape, NAV / PAR 1, PAR 2, PAR 3, Enter, Edit Input 1 - 2, Edit Output 1 - 6 Display: 6 x output limit, 2 x input mute LED, 6 x output edit LED, 2 x input edit LED, 6 x output clip, 2 x input clip, 6 x output mute LED, 2 x 6-segment input level display, 6 x 5-segment output level display, multifunction LC display Line inputs: 3 Line input connectors: 1 x stereo digital (SPDIF coax), 2 x XLR (bal.) Line outputs: 6 Line output connectors: XLR (balanced)
Interfaces: RS485 (in & out), USB Mains connector: IEC socket Operating voltage: 90 V AC - 250 V AC, 50 - 60 Hz W*H*D: 482mm*44,5mm*225mm
Weight: 3.5kg |
