Dual 8" two way line array active speaker
The E-VL208A is dual 8" vertical line source concert system with variable curvature, primarily designed for live performances from small to large indoor and outdoor venuse. The power handling is 650W RMS each top.
Application
¡¤ Large and medium scale performance
¡¤ Large and medium-sized stadium
¡¤ Theater and auditorium
¡¤ Concert,pub,club
Model: VL208A
Type: Dual 8'' two way line array active speaker
Acoustical Specifications
Drivers:2¡Á8£¢(200mm)/2.5£¢voice coil LF
Frequency Range(-6dB): 65 - 19 kHz
Max. SPL(1m): 135 dB
Horizontal Dispersion(-6dB): 100¡ã
Vertical Dispersion(-6dB): 10¡ã¡Á 1
Max Qty of rigging (12 : 1 Safety Factor, using original accessories) : 24 pcs
Vertical Dispersion(-6dB): LF: RMS / Peak (AES): 400 W / 1600 W
Amplifier:500W inside
HF: RMS / Peak (AES): 150 W / 600 W
Connectors:2¡ÁSpeakon NL4, 2¡ÁXLR
Net Weight:32.5kg/pcs
Dimension (W x D x H):725mm X 370mm X 235mm
